ESMACH TSPI B-H Tilting and Dumping Mixer




TSPI is a compact self-tipping Mixer, comprising a SPI FE spiral mixer coupled with a hydraulic lifter, designed to raise the entire structure vertically and, with a rotating movement, tip the dough in the bowl onto the worktable below or inside the special volumetric divider hopper, on the right or on the left, depending on the model chosen.

  • Shockproof thermoformed ABS head cover
  • Electronic control panel
  • Stainless steel bowl and protection grid
  • High-resistance stainless steel spiral arm and breaker bar
  • Electric system installed in IP55 grade protection box
  • Hard torsion-resistant single-unit structure, anticorrosive double epoxy powder-coated
  • Access for easy inspection and regular maintenance
  • Hydraulic lifting and tipping system
  • Column positioned on the right-hand side or left-hand side, high or low, depending on tipping requirements
  • Up-down movements by “hold-to-run” controls
